LONGi LR5 Connector for Reliable PV Module Connections
LONGi LR5 Connector provides stable and efficient connections for LONGi LR5 PV modules in modern solar power systems.
The LONGi LR5 Connector is designed specifically for PV module connections within LONGi LR5 solar panel systems. Engineered to ensure secure contact and stable power transmission, it supports efficient integration between PV modules and balance-of-system components. Its durable design makes it suitable for long-term use in outdoor solar applications.
Technical Data
Rated Current | Value |
|---|---|
Rated Current | 40A/50A(IEC), 30A/40A(UL) |
Rated Voltage | 1500V(IEC) / 1500V(UL) |
Cable Type | 4mm² / 6mm² |
OD of Suitable Cables | Type I φ5.6mm＜OD≤φ6.6mm Type II φ6.6mm＜OD≤φ7.2mm Type III φ4.5mm≤OD≤φ5.6mm |
Degree of Protection, mated | IP68(1.2m, 1h) |
Degree of Protection, unmated | IP2X |
Ambient Temperature Range | -40°C~+85°C |
Safety Class | II |
FAQs
Q1: What is the LONGI LR5 connector used for?
It is used for electrical connections on LONGI LR5 solar modules.
Q2: Is this connector specific to certain PV modules?
It is designed to match the connection requirements of LR5 modules.
Q3: Does it support stable power output?
Yes, it ensures consistent electrical transmission from the module.
Q4: Where is the LR5 connector typically installed?
It is installed at the module output interface.
Q5: Is it suitable for outdoor solar environments?
It is designed for standard outdoor PV conditions.
